Basic Info.
Model NO.
ANBIT-25HP
Type
Twin-Screw Compressor
Transport Package
Normal Packing
Trademark
ABT
Origin
China
Product Description
Product Description
Details Images
Company Profile
Shenyang ABT Drilling Equipment Co., Ltd. mainly provides holistic drilling solutions, serving the mining, stone crushing, water conservancy drilling industry, to help you solve the problem of drilling at high efficiency and low cost. We mainly provide mobile air compressors, drilling rigs, hammer, drill bit, crushers, underground water detector.We are your trustworthy partner.
FAQ
1.Is it difficult to operate and make the graph?
The instrument is easy to operate and we will send you the detailed operation manual via email.
The detector directly mapping with one button, no need computer drawing mapping.
2.What is the accuracy?
Our natural electric field instruments have been made for more than ten years, with advanced technology and market test. We have obtained many invention patents. Our customer feedback rate reaches 100%. Accuracy over 95%.
3.How about after-sales service?
2 year warranty.Free data service for life.The professional geologist give the suggestions and 24hours online.
Our company provides you with a full set of industrial gas solutions, including screw air compressor, piston air compressor, permanent magnet inverter air compressor, special air compressor for blowing bottles, special air compressor for laser cutting and a full set of post-treatment system.Professional solution to all your gas needs, high equipment reliability, remarkable energy saving effect.
Details Images
| Screw compressor technical parameters | ||||||
| Model | ALB-25HP | ALB-30HP | ALB-40HP | ALB-50HP | ALB-60HP | |
| Free Air Delivery/ Discharge Pressure | M³/Min/MPa | 3.1/0.7 | 3.8/0.7 | 5.2/0.7 | 6.8/0.7 | 7.8/0.7 |
| 2.9/0.8 | 3.6/0.8 | 5.0/0.8 | 6.2/0.8 | 7.3/0.8 | ||
| 2.7/1.0 | 3.2/1.0 | 4.3/1.0 | 5.6/1.0 | 7.0/1.0 | ||
| 2.2/1.3 | 2.9/1.3 | 3.7/1.3 | 4.8/1.3 | 5.8/1.3 | ||
| Compressed series | single stage | |||||
| Environmental temperature | -5ºC-+45ºC | |||||
| Cooling mode | Air-Cooled | |||||
| Discharge Temperature | ºC | 55ºC | ||||
| LubricantL | L | 18 | 30 | |||
| Noise | dB(A) | ≤72 | ||||
| Drive method | Direct drive | |||||
| Power supply | V/PH/HZ | 380V/50HZ | ||||
| power | KW | 18.5 | 22 | 30 | 37 | 45 |
| Starting type | Frequency conversion | |||||
| Dimensions (mm) | Length | 1380 | 1500 | |||
| Width | 850 | 1000 | ||||
| Height | 1160 | 1320 | ||||
| Weight | KG | 460 | 470 | 480 | 760 | 780 |
| Air Outlet Pipe Diameter | imch/mm | R1 " | R1 1/2" | |||
Company Profile
Shenyang ABT Drilling Equipment Co., Ltd. mainly provides holistic drilling solutions, serving the mining, stone crushing, water conservancy drilling industry, to help you solve the problem of drilling at high efficiency and low cost. We mainly provide mobile air compressors, drilling rigs, hammer, drill bit, crushers, underground water detector.We are your trustworthy partner.
FAQ
1.Is it difficult to operate and make the graph?
The instrument is easy to operate and we will send you the detailed operation manual via email.
The detector directly mapping with one button, no need computer drawing mapping.
2.What is the accuracy?
Our natural electric field instruments have been made for more than ten years, with advanced technology and market test. We have obtained many invention patents. Our customer feedback rate reaches 100%. Accuracy over 95%.
3.How about after-sales service?
2 year warranty.Free data service for life.The professional geologist give the suggestions and 24hours online.
