Basic Info.
Model NO.
HZRC-2000+
Test Report
Yes
Work Temperature
-10ºC~55ºC
MOQ
1
After Sale Service
Yes
Certificate
ISO CE
Resistance Range
0.01-1200Ω
Current Range
0.00mA-20.0A
Dimensions
285*85*56(mm)
Transport Package
Wooden Box with Foam Inside
Specification
CE/ISO/IEC
Trademark
HuaZheng
Origin
Hebei, China
HS Code
9030332000
Production Capacity
100 PCS/Month
Product Description
Factory High Accuracy Digital Grounding Clamp Earth Resistance Test Machine
Model of Series
| Model | Jaw Size (mm) | Range of Resistance (Ω) | Range of Current (A) | Storage Function | Alarm Function |
| HZRC2000+ | 65×32 | 0.01--1200 | -- | 99 Units | √ |
| HZRC2000A+ | 65×32 | 0.01--200 | -- | 99 Units | √ |
| HZRC2000C+ | 65×32 | 0.01--1200 | 0.0--20.0 | 99 Units | √ |
| HZRC2100+ | φ32 | 0.01--1200 | -- | 99 Units | √ |
| HZRC2100A+ | φ32 | 0.01--200 | -- | 99 Units | √ |
| HZRC2100C+ | φ32 | 0.01--1200 | 0.0--20.0 | 99 Units | √ |
Ranges and Accuracy of Measurement
| Mode | Range | Resolution | Accuracy |
| Resistance | 0.010Ω-0.099Ω | 0.001Ω | ±(1%+0.01Ω) |
| 0.10Ω-0.99Ω | 0.01Ω | ±(1%+0.01Ω) | |
| 1.0Ω-49.9Ω | 0.1Ω | ±(1%+0.1Ω) | |
| 50.0Ω-99.5Ω | 0.5Ω | ±(1.5%+0.5Ω) | |
| 100Ω-199Ω | 1Ω | ±(2%+1Ω) | |
| 200Ω-395Ω | 5Ω | ±(5%+5Ω) | |
| 400-590Ω | 10Ω | ±(10%+10Ω) | |
| 600Ω-880Ω | 20Ω | ±(20%+20Ω) | |
| 900Ω-1200Ω | 30Ω | ±(25%+30Ω) | |
| *Current (True-RMS) | 0.00mA -9.00mA | 0.05mA | ±(2.5%+2mA) |
| 10.0mA -99.0mA | 0.1mA | ±(2.5%+10mA) | |
| 100mA -300mA | 1mA | ±(2.5%+20mA) | |
| 0.30A-2.99A | 0.01A | ±(2.5%+0.1A) | |
| 3.0A-9.9A | 0.1A | ±(2.5%+0.5A) | |
| 10.0A-20.0A | 0.1 A | ±(2.5%+1 A) |
Measured Current Frequency: 50Hz/60Hz
Setting Range of Resistance Alarm Critical Value: 1Ω-199Ω
*Setting Range of Current Alarm Critical Value:1mA -499mA
3. Specifications
Instrument safety: IEC/EN61010-1, IEC/EN6010-2-032Insulation: double insulation
Pollution degree: class II
Overvoltage category: CAT III 150V to ground, Max 20A
Degrees of protection:
-IP30, Group III equipment as per EN 60529 Ed 92
-IK04, as per EN 50102 Ed 95
Dimensions(L×W×H):
-Long elliptic jaw: 285mm×90mm×66mm; (11×4×3 inches)
-Round jaw: 260mm×90mm×66mm;(10×4×3 inches)
Span of Jaw: Long elliptic jaw 35mm; round jaw 32mm
Weight (including batteries): Long elliptic jaw-1160g, Round jaw-1120g
Battery type: 4 ×1.5V alkaline LR6 AA battery
Low battery indication: is displayed
Internal consumption: <50mA
Auto Power off: after 5 minutes of idleness
Display: 4 LCD, sign, decimal point and backlight
Memory size: 99 Units of Reading
Environment (Temperature & Relative Humidity):
-Working: -10°C~55°C, 10%RH-90%RH
-Storage: -20°C ~60°C, below 70%RH
Range shift: Full range automatic shifting
External magnetic field: <40A/m
External electric field: <1V/m
Data upload interface: RS232 (Optional)
Company Information
Customer Visit
Exhibition
| HuaZheng Electric Manufacturing (Baoding) Co.,Ltd is the supplier of the State Grid in China.It means we are the supplier of the Chinese Government.And our products spread throughout the whole China. What's more, our customers come from different countries like America, England, Bulgaria, Brazil, Chile, Malysia, Vietnam and so on. Our main products are Insulation Oil Tester, Cable Fault Locator, Power Quality Analyzer, High Voltage Generator, High Voltage Capacitor, Testing Transformer and so on. |
