Basic Info.
Product Description
# Weld spot energy distirbution is uniform,with high quality spot required for welding characteristic.
# Suitable for welding and splicing of various metal materials.
# Fast processing speed.
# Small themal deformation and heat afected area..
# Parts can be subjected tp local heat treatment.
# No noise processing.
# Using domestic top brand fiber laser source, excellent beam quality, maintenance-free, photoelectric conversion efficiency more than 25%, pump source service life more than 100,000 hours.
| Model | LE-1000 |
| Laser source | MAX / Raycus / JPT / Reci / IPG |
| Laser power | 1000W ( Optonal ) |
| Cable length | Standard 10m, optional 15m |
| Control System | Au3tech / Chaoqing / Qilin |
| Wavelength | 1064/1070 nm |
| Welding speed range | 0~120 mm/s |
| Cooling chiller | Industrial water chiller |
| Welding thickness recommendations | 0.2 - 2mm |
| Welding gap requirements | ≤0.5mm |
| Humidity range of working environment | < 70% No condensation |
| Working environment temperature range | 15~35 ºC |
Inner package: Stretch film and and water-proof film.
Outside package: Standard export plywood case.
By sea/train/air, we can do EXW/FOB/CFR/CIF/DDU/DDP trading terms.
Three years warranty.
7/24 after sale service.
Customer will be able to get free training advice in our factory.
Can also get free suggestion, consultation, technical support and service by Email/Tel/WhatsApp/Skype, etc.
Any question or problem, show us pictures or videos, and then we will try our best to help you as soon as possible.
Free parts will be provided if broken not human reason within warranty.
Engineer available to overseas service.
T/T 100% in advance, and we start to manufacture this machine after receiving the payment, some models on stock and fast delivery.
We will send you our machine pictures and testing video to confirm, next, arrange the packing and shipping after all confirmed.
Q: Which one is suitable for me?
A: Tell us below information
1) Max size of your material, to choose most suitable model.
2) Maximum working thickness, materials, to choose suitable power.
3) Industry information and sample photos, we will recommend you best model based on our many years experience in this field.
Q: How to install and run the machine?
A: Our technician have installed the machine before shipping. For some small parts installation, we will send detail training video, user's manual along with the machine. Most customers can learn by themselves.
Q: How can I do if the machine goes wrong?
A: If confronted with such problems, please contact us asap and do not try fix the machine by yourself or someone else. We can provide WeChat/Whatsapp/Email/Phone, will response within 24 hours as quick as we can to solve it for you, till to solving all questions.
Q: What's your MOQ?
A: 1 set, we will give you support with our heart and soul.
