Basic Info.
Model NO.
HPS30
Phase
Three
Output Power
>1000W
Certification
SAA, CE, ISO9001, CCC
Brand
Bessent
Type
DC/AC Inverters
Power Source
Solar Power, Wind Power
Circuit Topologies
Push-pull Type
Nature of Wave String
Sine Wave Inverter
Product Name
on Grid Inverter
Inverter Type
MPPT
Rated Output Power
30kw
Input Voltage
400VDC
Output Voltage
480-800V
Input Current
50/100A
Output Frequency
50Hz/60Hz
Max. Efficiency
85%
Application
off-Grid Hybrid Solar System
Protection
IP20
Transport Package
Carton
Specification
700*1660*600mm
Trademark
Bessent
Origin
Jiangsu
Production Capacity
500000 Piece/Pieces Per Month
Packaging & Delivery
Package Size
74.00cm * 170.00cm * 64.00cm
Package Gross Weight
355.000kg
Product Description
Lithium battery storage system 30kw 50kw 100kw 150kw on grid solar inverter
| Type | HPS30 | HPS50 | HPS100 | HPS150 |
| Apparent power | 33KVA | 55KVA | 110KVA | 165KVA |
| Rated power | 30KW | 50KW | 100kW | 150kW |
| Rated voltage | 400V | 400V | 400V | 400V |
| Rated current | 43A | 72A | 144A | 217A |
| Voltage range | 360V- 440V | 360V- 440V | 360V- 440V | 360V- 440V |
| Rated frequency | 50/60Hz | 50/60Hz | 50/60Hz | 50/60Hz |
| Frequency range | 45~55/55~65Hz | 45~55/55~65Hz | 45~55/55~65Hz | 45~55/55~65Hz |
| THDI | <3% | <3% | <3% | <3% |
| PF | 0.8lagging~0.8leading | 0.8lagging~0.8leading | 0.8lagging~0.8leading | 0.8lagging~0.8leading |
| AC connection | 3/N/PE | 3/N/PE | 3/N/PE | 3/N/PE |
| AC input | 60kVA | 100kVA | 200kVA | 240kVA |
| Protection degree | IP20 | IP20 | IP20 | IP20 |
| Noise emission | <65dB(A)@1m | <65dB(A)@1m | <65dB(A)@1m | <65dB(A)@1m |
| Operating temperature | -25°ºC~+55°C | -25°ºC~+55°C | -25°ºC~+55°C | -25°ºC~+55°C |
| Cooling | Forced-air | Forced-air | Forced-air | Forced-air |
| Relative humidity | 0-95% non-condensing | 0-95% non-condensing | 0-95% non-condensing | 0-95% non-condensing |
| Maximum altitude | 6000m (derate over 3000m) | 6000m (derate over 3000m) | 6000m (derate over 3000m) | 6000m (derate over 3000m) |
| Dimension (W/H/D) | 700*1660*600mm | 950*1860*750mm | 1200*1900*800mm | 1200*1900*800mm |
| Weight | 355kg | 610kg | 948kg | 1230kg |
| Build-in transformer | Yes | Yes | Yes | Yes |
| Transfer between on/off grid | Automatic≤10ms | Automatic≤10ms | Automatic≤10ms | Automatic≤10ms |
| Standby consumption | <30W | <30W | <30W | <30W |
